Style 661

USER CHANGEABLE COLOR is standard on all BRG LED digital clocks.


661C User Changeable Multi-Color Time Zone Display

BRG Time Zone Clocks are accurate for life without the need for manual or external time updates.  A GUI touch screen IR remote control is available to ease configuration.

BRG's 661 series allows you to change the color of any zone or zones with ease.

  • Change the color of 1 Zone, Several Zones or All Zones
  • Program time zones as situations change
  • 7 Colors Available: Red, Blue, Green, Yellow, Magenta, Cyan or White
  • Smoked lens to highlight the 7 different colors
  • Highlight your operations area or hot zone by programming a separate color
  • Make Zulu Time stand out by programming it in a different color so it will stand out
  • Tired of red LEDs switch to another color anytime.
  • Provides great flexibility
  • Adapt easily to a changing world

Introducing BRG's New Time Commander Graphical Remote Control Programmer Option


Click for more information

Even though our fixed zone time zone clocks come with an IR remote control to change LED zone color and brightness, BRG offers the Time Commander Option.

  • Allows you to change the:
    • LED Colors
    • Intensity (global or by zone)
  • Use on multiple time zone clocks
  • Easy to use
  • Eliminates the need for a computer interface
  • Wireless IR remote
  • Color touch screen for ease
  • Large 7 inch color LCD touch screen display
  • Rechargeable Battery

The Time Commander is only compatible with BRG Time Zone Clocks Manufactured after October 2018

Call 866-252-2704 or 316-530-8854

Time Zone Display Fixed Style 661



Model 661R with User Changeable Multi-Color LEDs

The 661 series time zone clocks have bar-segment LED time displays with white vinyl zone labels below. 661 models can display 1 to 10 time zones.

  • All zones are precisely synchronized with one another.
  • Factory synchronized with the U.S. Atomic Clock.
  • Accurate for Life – no manual adjustments are required for the life of the display, no sync wires, no radios, no problems.
  • Time and configuration are maintained during shipping and power outages
  • Operating Voltage: 90-265 volts AC.
  • Many control, sync methods, power and color options are available
  • Includes BRG's F5 Anodized Black Aluminum Frame  Learn More
For easy clock management, an infrared (IR) remote control is included with every 661 model. You can specify a radio (RF) remote, if preferred for no additional charge.

Call 866-252-2704 or 316-530-8854

Now with 3X more LED's than competing products!

If we have quantity on hand, it will ship within one week of receiving the time zones.  If the quantity on hand is 0, that model with ship within 2 weeks of receiving the time zones.

1.8" Bar Segment LED Models - Viewing Distance is 40 ft.

Model
Zones
Time Display
Label Size White Vinyl
Inches
Qty on Hand
Download Spec Sheet

Buy a Multi-Color LED Clock Online or
order through GSA Advantage.

GSA orders please call with zone labels

H
W
661A 2 1.8" 0.75" 6.25 20.25 4
661B 3 1.8" 0.75" 6.25 30.25 6
661C 4 1.8" 0.75" 6.25 40.25 8
661D 5 1.8" 0.75" 6.25 50.25 7
661E 6 1.8" 0.75" 6.25 60.25 11
661F 7 1.8" 0.75" 6.25 70.25 8
661G 8 1.8" 0.75" 6.25 80.25 1
661V 9 1.8" 0.75" 6.25 90.25
661W 10 1.8" 0.75" 6.25 96.25

Modular 1.8" Bar Segment LED Models
- Viewing Distance is 40 ft.
Model Phys. Pos. Sections Displays

Dimensions

Download Spec Sheet Buy a Multi-Color LED Clock Online or through GSA Advantage.
Time Vinyl Label Height Width
661DD 10 2 1.8" 0.75" 6.25 100.5
661CBC 11 3 1.8" 0.75" 6.25 110.75
661EE 12 2 1.8" 0.75" 6.25 120.5
661CDC 13 3 1.8" 0.75" 6.25 130.75
661FF 14 2 1.8" 0.75" 6.25 140.5
661DDD 15 3 1.8" 0.75" 6.25 150.75
661GG 16 2 1.8" 0.75" 6.25 160.5
661DFD 17 3 1.8" 0.75" 6.25 170.75
661VV 18 2 1.8" 0.75" 6.25 180.5
661EFE 19 3 1.8" 0.75" 6.25 190.75
661EGE 20 3 1.8" 0.75" 6.25 200.75
661FFF 21 3 1.8" 0.75" 6.25 210.75
661FGF 22 3 1.8" 0.75" 6.25 220.75
661GFG 23 3 1.8" 0.75" 6.25 230.75
661GGG 24 3 1.8" 0.75" 6.25 240.75
Click Here to downlaod a .PDF File of 1.8" Modular Time Zone Sizes

Call 866-252-2704 or 316-530-8854


2.5" Bar Segment LED Models -Viewing Distance is 75 ft.

Model
Zones
Time Display
Label Size White Vinyl
Inches
Qty on hand
Download Spec Sheet

Buy a Multi-Color LED Clock Online or
order through GSA Advantage.

GSA orders please call with zone labels

H
W
661H 2 2.5" 1.00" 8.25 24.25 7
661I 3 2.5" 1.00" 8.25 36.25 3
661J 4 2.5" 1.00" 8.25 48.25 6
661K 5 2.5" 1.00" 8.25 60.25 9
661L 6 2.5" 1.00" 8.25 72.25 4
661M 7 2.5" 1.00" 8.25 84.25 5
661N 8 2.5" 1.00" 8.25 96.25 0

Modular 2.5" Bar Segment LED Models
- Viewing distance is 75 ft.
Model Phys. Pos. Sections Displays

Dimensions

Download Spec Sheet Buy a Multi-Color LED Clock Online or through GSA Advantage.
Time Vinyl Label Height Width
661III 9 3 2.5" 1.0" 8.25 108.75
661KK 10 2 2.5" 1.0" 8.25 120.50
661JIJ 11 3 2.5" 1.0" 8.25 132.75
661LL 12 2 2.5" 1.0" 8.25 144.5
661JKJ 13 3 2.5" 1.0" 8.25 156.75
661MM 14 2 2.5" 1.0" 8.25 168.5
661KKK 15 3 2.5" 1.0" 8.25 180.75
661NN 16 2 2.5" 1.0" 8.25 192.5
661LKL 17 3 2.5" 1.0" 8.25 204.75
661LLL 18 3 2.5" 1.0" 8.25 216.75
661LML 19 3 2.5" 1.0" 8.25 228.75
661LNL 20 3 2.5" 1.0" 8.25 240.75
661MMM 21 3 2.5" 1.0" 8.25 252.75
661MNM 22 3 2.5" 1.0" 8.25 264.75
661NMN 23 3 2.5" 1.0" 8.25 276.75
661NNN 24 3 2.5" 1.0" 8.25 288.75
Click Here to downlaod a .PDF File of 2.5" Modular Time Zone Sizes

Call 866-252-2704 or 316-530-8854


4.0" Bar Segment LED Models

Model
Zones
Time Display
Label Size White Vinyl
Inches
Qty on Hand
Download Spec Sheet

Buy a Multi-Color LED Clock Online or
order through GSA Advantage.

GSA orders please call with zone labels

H
W
661O 2 4.0" 1.50" 10.25 30.25 1
661P 3 4.0" 1.50" 10.25 45.25 5
661Q 4 4.0" 1.50" 10.25 60.25 6
661R 5 4.0" 1.50" 10.25 75.25 4
661S 6 4.0" 1.50" 10.25 90.25 6
661T 7 4.0" 1.50" 10.25 96.25
661U 8 4.0" 1.50" 10.25 120.25

Modular 4.0" Bar Segment LED Models
- Viewing distance 100 ft.
Model Phys. Pos. Sections Displays

Dimensions

Download Spec Sheet Buy a Multi-Color LED Clock Online or through GSA Advantage.
Time Vinyl Label Height Width
661OPO 7 3 4.0" 1.5" 10.25 105.75
661QQ 8 2 4.0" 1.5" 10.25 120.5
661PPP 9 3 4.0" 1.5" 10.25 135.75
661RR 10 2 4.0" 1.5" 10.25 150.50
661QPQ 11 3 4.0" 1.5" 10.25 165.75
661SS 12 2 4.0" 1.5" 10.25 180.5
661QRQ 13 3 4.0" 1.5" 10.25 195.75
661RQR 14 3 4.0" 1.5" 10.25 210.75
661RRR 15 3 4.0" 1.5" 10.25 225.75
661RSR 16 3 4.0" 1.5" 10.25 240.75
661SRS 17 3 4.0" 1.5" 10.25 255.75
661SSS 18 3 4.0" 1.5" 10.25 270.75
661QQPQQ 19 5 4.0" 1.5" 10.25 286.25
661RRRR 20 4 4.0" 1.5" 10.25 301.00
661QQRQQ 21 5 4.0" 1.5" 10.25 316.25
661QQSQQ 22 5 4.0" 1.5" 10.25 331.25
661RRPRR 23 5 4.0" 1.5" 10.25 346.25
661SSSS 24 4 4.0" 1.5" 10.25 361.0
Click Here to downlaod a .PDF File of 4.0" Modular Time Zone Sizes


BRG Time Zone Clocks can be configured to display the following special information when specified at the time of purchase. Not all features can be included in every clock due to memory constraints or operational conflicts:

  • ATO Military Day Code (alpha displays only)
  • ISO8601 Work Week (alpha and/or numeric displays)
  • Julian Date (day of the year - alpha and/or numeric displays)
  • Week of the Year (alpha displays only)
  • Sunrise and/or Sunset Time (alpha and/or numeric displays)
  • Military Shipping Code A-Z, no I or O (alpha displays only)

Call 866-252-2704 or 316-530-8854




Online Orders

The Time Zone Clocks that are ordered on-line are built with the specifications below:

  • Red Bar Segment LEDs for Time
  • White Vinyl Zone Labels
  • OCXO Oscillator that is accurate to +/- 1 second over 20 years
  • IR Remote Control is standard, RF remote available as an option
  • 12 ft power cord with U.S. plug
  • 2 week lead time

If you want custom displays, multiple colors, an oscillator upgrade, GSA pricing or want to speak to a sales professional, Call 800-295-0220 for Sales Assistance

Download Spec Sheet

Color Options

Photo Below is a 6610E with user changeable multi-color LEDs & frosted lens
Change to red, blue, green, yellow, magenta, cyan or white any time you want


Closeup of the 6610E-C with with user changeable multi-color LEDs, frosted lens
